COLD PRESS OIL MILL PLANT

About COLD PRESS OIL MILL PLANT

Special Facilities / Features In Tinytech Expeller

• Chamber cage opens on hinges simply by tilting of chamber halves. Drudgery of lifting of heavy weights of clamping bars and chamber halves are totally eliminated.
• Thickness of oil cake can be changed while running of expeller. This is unique facility. It enables to change thickness of cake while running of expeller. This is unique facility of Tinytech expeller.
• Oil pump is now integral part of oil expeller and hence no separate pump required.
• Due to ready foundation frame, No foundation of any machine required in the ground. So Installation becomes easy & plant can be started within 24 hours. Also you can shift machine easily from one place to another as and when required.
• 6 taper roller bearings make expeller very sturdy and durable. No ball bearings fitted anywhere.
• As expeller is very compact, it is economical to import by air freight for land locked countries.
• Feedbox mouth has been made bigger so that expeller can crush cotton seeds effectively.
• Main pulley Shaft diameter is 62 mm which is highest in the industry.

Features Of Oil Expeller

• Superior Performance of the Machine
• Cast Iron Bodies & Base
• Single Reduction Gear Box with Spur Gears, low maintenace
• Case Hardened Worm Assembly
• Superior Quality of Oil & Cake
• Long Life Span and Durability
• Latest innovative technology
